Diesel concrete mixer for sale is a core equipment for achieving uniform concrete mixing in construction, and its diesel power system ensures no reliance on electricity for field operations. It fully mixes cement, aggregates, and water into uniform concrete, laying a solid foundation for projects. Composed of a mixing drum, feeding/discharging mechanisms, water supply, prime mover, drive, frame, and supports, it’s scientifically structured and reliable. Our diesel mixer for sale is sold to Mexico, Nigeria, Australia, the US, Malaysia, Thailand, the Philippines, Indonesia, etc., and is highly favored globally. Click it for quotes!
【WhatsApp/WeChat/Phone】+86 13837122632
Diesel Concrete Mixer for Sale Technical Parameters
Different models have diverse specs to match construction needs:
| Model | YG350 | YG400 | YG500 | YG750 | |
| Working performance | Discharge capacity | 350L | 400L | 500L | 750L |
| Feed capacity | 560L | 650L | 800L | 1200L | |
| Productivity | 10-14m3/h | 18-28m3/h | 14-18m3/h | 20-22m3/h | |
| Speed | 14r/min | 14r/min | 13r/min | 13r/min | |
| Maximum aggregate size | 60mm | 60mm | 60-80mm | 60-80mm | |
| Motor | Stirring motor | 5.5KW | 7.5KW | 11KW | 15KW |
| listing motor | 5.5KW | 7.5KW | 5.5KW | 7.5KW | |
| Pump motor | 0.55KW | 0.75KW | 0.75KW | 1.1KW | |
| Dimension | 2766*2140*3000mm | 3850*2200* 2850mm | 5226*2200* 5460mm | 6116*2056* 6060mm | |
| Total weight | 1950kg | 1950kg | 3100kg | 4200kg | |
Why Choose YG’s Concrete Mixer Diesel Engine?
1. Strong Power, Efficient Mixing
YG’s diesel concrete mixer for sale delivers robust power. The YG750 has a 15KW stirring motor—30% more efficient than ordinary mixers, slashing project timelines.
2. Durable & Cost – Effective
Made with high-quality steel drums (wear-and-impact-resistant) and specially treated key parts (like drives/bearings), it reduces breakdowns. This reduces maintenance expenses, improving the cost-effectiveness of your investment in the diesel engine concrete mixer machine price.
3. Flexible & User – Friendly
Its human-centered feeding/discharging design enables quick material handling. Compact sizes (e.g., YG350: 2766*2140*3000mm) allow easy movement in tight indoor/outdoor spaces, suiting varied projects.
4. Labor – Saving Operation
The automated feeding, mixing, and discharging processes minimize manual labor. Workers only need to add raw materials and set parameters—no heavy-duty manual mixing. This cuts labor costs and reduces worker fatigue, boosting overall construction efficiency.
5. Eco – Friendly Design
Equipped with advanced exhaust treatment systems, YG’s mixers reduce harmful emissions. The optimized fuel-injection systems also lower fuel consumption, cutting carbon footprints. Plus, the sealed mixing drums prevent dust and slurry leakage, keeping construction sites clean and eco-friendly.
Diesel Concrete Mixer for Sale: Application Scenarios
1. Rural Home Construction
Small concrete mixer diesel engine models (YG350/YG400) shine. Their compact size fits narrow rural yards; 350L – 400L discharge meets small-batch needs (foundations/walls). 10 – 14m³/h productivity speeds up home builds.
2. Urban Road & Bridge Projects
Large models (YG500/YG750) handle high-demand tasks. Road widening/bridge pile pouring requires continuous, high-volume concrete. YG500 (14 – 18m³/h) and YG750 (20 – 22m³/h) mix 60 – 80mm aggregates, supplying high-grade concrete for non-stop urban infrastructure progress.
3. Water Conservancy & Mining
In dam building/mining tunnel support, the mixer is vital. Diesel power works off-grid in remote areas. It meets strict concrete permeability (water projects) and durability (mining) demands, ensuring quality and safety.
Trust YG’s Diesel Mixer for Sale
YG factory strictly controls quality for stable, reliable products. Whether for diesel engine concrete mixer machine price value, durability, or practicality—we deliver. All models feature powerful, fuel-efficient diesel engines, adapting to complex sites (rural/urban) for stable, schedule-boosting operation. YG also has other popular products like concrete batch plants, micro excavators, mini concrete pumps, mortar sprayers, fog cannons, sand blasting machines, shotcrete machines, wet shotcrete machines, and industrial diesel generators. Contact us for details/quotes now.
【WhatsApp/WeChat/Phone】+86 13837122632
