Water Well Drill for Sale

When looking for a reliable water source solution, an efficient water well drill is essential. YG Machinery offers various models of water well drill for sale, designed for different terrains and needs. These machines combine advanced hydraulic technology to ensure efficient drilling of water wells, agricultural irrigation wells, and more, even in mountainous and rocky formations. If you are concerned about water well drilling machine price or searching for a water drilling rig for sale, the YG series is undoubtedly a cost-effective choice. In addition, YG also provides vertical core drilling rigs, fully hydraulic core drilling rigs, and small water well drills. Feel free to contact us anytime for a customized quotation!【WhatsApp/WeChat/Phone】+86 13837122632

Get a Free Quote

YG Series Popular Water Well Drill for Sale Parameter Table

Model	YG-180	YG–200	YG–300	YG–300A	YG–400	YG–600
Drilling hole diameter	140-254mm	140-305mm	140-325mm	140-325mm	140-350mm	140-350mm
Drilling depth	180m	200m	300m	300m	400m	600m
One-time advance length	3.4m	3.4m	6.6m	3.4m	6.6m	6.6m
Walking speed	2.5km/h	2.5km/h	2.5km/h	2.5km/h	2.5km/h	2.5km/h
Climbing angles (Max.)	30	30	30	30	30	30
Equipped capacitor	55kw	65-70kw	84kw	75.8kw	92kw	115kw
Using air pressure	1.7-2.5mpa	1.7-3.0mpa	1.7-3.3mpa	1.7-3.0mpa	1.7-3.5mpa	1.7-3.5mpa
Air consumption	17-31m³/min	17-30m³/min	17-35m³/min	17-35m³/min	17-35m³/min	17-35m³/min
Drill pipe length	1.5m, 2.0m, 3.0m	1.5m, 2.0m, 3.0m	1.5m, 2.0m, 3.0m,6.0m	1.5m, 2.0m, 3.0m	1.5m, 2.0m, 3.0m,6.0m	1.5m, 2.0m, 3.0m,6.0m
Drill pipe diameter	76mm, 89mm	76mm, 89mm	89mm, 102mm	76mm, 89mm, 102mm	89mm,102mm,108mm	102mm,108mm,114mm
Rig lifting force	15t	12t	20t	16t	22t	28t
Swing speed	45-65rpm	45-70rpm	45–115rpm	40–70rpm	45-115rpm	45–115rpm
Swing torque	3200-4600(N.m)	3500-4800(N.m)	6200-8500(N.m)	5700-7500(N.m)	6500-9000(N.m)	8500-11000(N.m)
Dimension	3800*1500*2200mm	4000*1750*2450mm	5900*2000*2850mm	4100*1950*2600mm	5900*2100*2850mm	6000*2200*2850mm
Weight	4500kg	5800kg	9000kg	7000kg	10000kg	12000kg

Get a Free Quote

Working Principle of Water Well Drill for Sale

• Power Start: The equipment is powered by a diesel engine, which first drives the hydraulic pump to generate a high-pressure oil circuit. This provides the energy foundation for the entire system, enabling the water well drill for sale to operate independently in remote areas.
• Hydraulic Control: Operators control movements through hydraulic valves on the console. For example, pushing the rotary control valve drives the hydraulic motor to rotate, making the drill rod spin; at the same time, the walking valve controls forward movement or turning.
• Drilling Action: The extension and retraction of the feed cylinder move the steel wire rope for feeding and lifting, coordinated with the forward rotation of the rotary device. When the drill bit contacts rock, compressed air drives the hammer to work, breaking the rock and blowing debris to the surface for continuous drilling.
• Auxiliary Functions: Hydraulic cylinders for stabilizers and the hoisting motor are controlled via valves, enabling equipment stabilization, drill rod loading/unloading, and other support operations to ensure safety and efficiency.

This design allows YG water well drills to maintain high reliability even in complex formations.

Get a Free Quote

Frequently Asked Questions about Water Drilling Equipment

To address common user concerns, we provide answers in bullet points to help you better understand YG machines:

• Hard Rock Drilling Capability: YG rigs are specially designed for hard rock. With an air compressor, they can easily handle rocky layers. The hammer system effectively breaks tough stone, ensuring drilling efficiency without geological worries.
• Engine Brand Options: The rigs use well-known Chinese brands such as Changchai, Yuchai, or Cummins, depending on the model. YG supports customization, allowing users to choose other engine brands according to project needs.
• Hydraulic Leg Operation: Equipped with automatic telescopic hydraulic legs, simplifying setup. This improves stability, especially on uneven terrain.
• Loading Method: The rig can be loaded onto a truck via a ramp or by lifting with hydraulic legs. This user-friendly design reduces transport time and makes deployment easier.
• Estimated Drilling Speed: Under standard conditions, YG rigs can drill 20–30 meters per hour. Actual speed depends on geological conditions but is generally higher than the industry average.

Get a Free Quote

How to Choose the Right water drilling rig for sale

• Define Drilling Requirements: First, evaluate the required depth and diameter. Refer to the YG parameter table: for shallow wells, YG-180 (180m depth) is suitable, while deep wells require YG-600 (600m depth). This ensures the equipment matches applications and optimizes the water well drilling machine price value.
• Consider Terrain and Power: For mountainous or rocky formations, choose a high-torque model such as YG-300A. Also check power configuration—higher-power models are better for continuous operations. YG rigs have strong climbing ability to adapt to various environments.
• Check Additional Features: Factors like drill pipe length options and compressor compatibility are crucial water drilling equipment details that influence flexibility. YG models support customization to enhance long-term value.
• Budget and Support: When comparing different water drilling rig for sale prices, prioritize after-sales service and technical support. YG offers comprehensive guarantees to minimize maintenance costs.

By following these steps, you can select an efficient and durable water well drill that maximizes your return on investment.

YG– Your Trusted Supplier of Water Well Drill for Sale

With advanced technology, reliable performance, and complete service, YG Machinery has become the first choice for many users. Whether you need small-scale irrigation solutions or large commercial drilling projects, YG’s water well drill for sale delivers excellent performance. We encourage you to use the above guide to explore YG’s series of rigs and experience the convenience brought by professional water drilling equipment. Contact the YG team today for a personalized quotation and start your efficient drilling journey! 【WhatsApp/WeChat/Phone】+86 13837122632
