How to turn waste newspapers and cartons into a sturdy shield for eggs? The answer lies in the eco-friendly magician of modern industry – the egg box machine. Through precise pulp molding technology, it efficiently converts waste resources into practical egg trays and egg boxes, providing a green and economical production path for the agricultural and packaging industries.【WhatsApp/WeChat/Phone】+86 13837122632
How the Egg Box Machine Turns Waste into Treasure
- Pulp mixing: Mix recycled waste paper (such as newspapers and cartons) with water and beat it into a uniform pulp.
- Vacuum adsorption molding: The pulp is injected into the mold. Under the action of negative pressure adsorption, the pulp evenly adheres to the surface of the egg tray mold to form a wet blank and filter out most of the water. This process accurately determines the final shape and structure of the product.
- Hot pressing drying and shaping: The wet blank is transferred to a high-temperature mold for hot pressing and drying. This step not only quickly removes water but also bonds the fibers tightly, finally producing a sturdy and shaped paper egg tray or egg box.
Why Do Farms Need an Egg Box Machine?
- Controllable cost, remarkable benefits: Using local waste paper as raw material for self-production and self-use greatly reduces the cost of packaging procurement in the long run, achieving cost reduction and efficiency improvement.
- Sanitary and safe, quality guaranteed: Building an egg carton making machine production line means having full control over raw materials and production environment, enabling the production of cleaner and sterile packaging that meets increasingly stringent food safety standards.
- Enhance brand and flexibility: Custom egg trays with brand logos can be independently produced to enhance the brand image. At the same time, the production plan is fully independent, which can flexibly respond to fluctuations in market demand.

YG Egg Box Machine Parameters
| Model | Capacity/H | Power/hour | Paper Consumption/H | Water Consumption/H | Dry System | Weight |
| YG-1500 – 4X1 | 1500pcs/h | 38kw | 120kg | 240kg | dry naturally | 3000kg |
| YG-2500 – 3X4 | 2500pc/h | 55kw | 200kg | 400kg | multi-layer drying | 4000kg |
| YG-3000 – 4X4 | 3000pcs/h | 60kw | 240kg | 480kg | multi-layer drying | 4800kg |
| YG-4000 – 4X8 | 4000pcs/h | 95kw | 320kg | 640kg | multi-layer drying | 7000kg |
| YG-5000 -5X8 | 5000pcs/h | 95kw | 400kg | 800kg | multi-layer drying | 8000kg |
| YG-7000 -6X8 | 7000pcs/h | 120kw | 480kg | 960kg | multi-layer drying | 10000kg |
Cross-Industry Applications of the Egg Tray Moulding Machine
- Food packaging: Produce coffee trays and pastry liners to meet the needs of coffee shops and bakeries, replacing plastic packaging.
- Industrial buffering: Make electronic component trays and small home appliance accessory trays, utilizing the buffering property of pulp to protect products during transportation.
- Agricultural seedling raising: Produce degradable seedling pots that can improve soil after degradation, in line with the trend of green agriculture.
- Cultural and creative field: Custom small storage boxes with cartoon shapes for stationery and jewelry storage, expanding creative uses.

FAQ about the Paper Egg Tray Machine
Q: Is the production raw material easy to obtain?
A: Very easy. The main raw material is waste paper, such as waste newspapers and cartons, which has a wide source and low cost, truly realizing waste utilization.
Q: What supporting equipment is needed to produce egg boxes?
A: In addition to the main machine, it is necessary to match with a pulper, vacuum pump, air compressor, dryer, etc. You can contact us to get an exclusive customized solution.
Q: Can products of different shapes and sizes be customized?
A: Of course. This is one of the advantages of the egg carton making machine. You can customize exclusive molds as needed to produce customized eco-friendly packaging suitable for various products.
