Improving warehouse efficiency has never been easier! The semi electric straddle stacker combines the advantages of manual and electric operation, making stacking and handling faster and safer. It is especially suitable for narrow aisle operations and medium-load scenarios, significantly enhancing warehouse handling efficiency while reducing labor costs. Whether in warehouses, distribution centers, or manufacturing plants, it serves as an intelligent and efficient handling solution. In addition, YG Machinery also offers fully automatic powered pallet stacker, forklifts, lifting platforms, and boom lifts for sale. Contact us for an exclusive quotation!【WhatsApp/WeChat/Phone】+86 13837122632
Semi Electric Straddle Stacker Specifications
Model | YG-15 (Walkie) | Lowered Height | 90mm |
Rated Load | 1500kg | Overall Length | 1860mm |
Load Center | 500mm | Fork Length | 1100mm |
Front Overhang | 745mm | Fork Size | 50×160×1100mm |
Wheel Track | 1185mm | Body Width | 800mm |
Weight (with battery) | 400kg | Fork Outer Width | 320 – 1030mm |
Wheels | Nylon | Ground Clearance at Axle Center | 40mm |
Front Wheel Size | 180×50mm | Turning Radius | 1425mm |
Rear Wheel Size | 80×70mm | Drive Type | Manual |
Front Wheel Track | 700mm | Lifting Speed (Loaded/Unloaded) | 0.08/0.1m/s |
Rear Wheel Track | 525mm | Lowering Speed (Loaded/Unloaded) | 0.12/0.09m/s |
Lifting Height | 1600 – 3500mm | Brake Type | Mechanical |
Lifting Motor Power | 1.6kW | Battery Weight | 43kg |
Battery 24V | 120Ah | Battery Size | 376×188×320mm |


Advantages of Semi Electric Straddle Stacker
- Double-sided reinforcement design: Strengthened structure ensures stability even under full load, preventing bending or deformation, and extending service life, making it suitable for high-frequency warehouse operations.
- One-touch operation system: Easy to operate, requiring no complex training, quickly improves stacking efficiency while reducing human errors, helping workers complete tasks faster and with greater confidence.
- Sealed hydraulic cylinder and plate chain: Imported seals effectively prevent oil leakage, while the double chain design ensures safe and reliable load handling, providing peace of mind even during continuous heavy-duty use.
- Electroplating process and independent foot brake: Corrosion-resistant and scratch-proof, with an independent foot brake allowing parking at any time, ensuring the safety of personnel and goods in various working environments.
- Strong adaptability: Suitable for short-distance stacking and handling, particularly demonstrating excellent flexibility and convenience in narrow aisles, meeting diverse storage needs of warehouses and distribution centers.
Application Scenarios of Semi Electric Pallet Stacker
The semi electric pallet stacker can be widely applied in various warehousing and logistics places:
- Warehouse storage: Quickly stacking and handling pallet goods, improving warehouse efficiency, and reducing labor intensity, while optimizing floor space usage and ensuring smooth inventory management.
- Distribution centers: Efficiently handling inbound and outbound goods, optimizing warehouse layout, and ensuring smooth goods circulation, which helps companies reduce delays and maintain on-time deliveries.
- Manufacturing plants: Transporting raw materials and semi-finished products within production workshops, reducing manual handling risks, and ensuring smooth material flow to support continuous production processes.
- Retail logistics: Ideal for small and medium-sized logistics warehouses and distribution scenarios, enabling fast shelf loading and unloading, while flexibly adapting to seasonal sales peaks and multi-point delivery demands.
Reasons for Choosing YG Machinery
The YG Machinery semi electric hand stacker not only greatly improves warehousing and handling efficiency but also effectively reduces labor costs and workplace injury risks. With flexible operation, reliable durability, and comprehensive safety design, enterprises can significantly increase operational efficiency in the short term and achieve higher investment returns in the long run. Whether for small and medium-sized enterprises or large logistics centers, the YG Machinery powered pallet stacker provides ideal support for improving warehouse efficiency and optimizing operational processes.
For more details about fully automatic powered pallet stacker, forklifts, lifting platforms, and boom lifts, or to get an exclusive quotation, please contact us via WhatsApp/WeChat/Phone +86 13837122632. YG Machinery will provide you with professional solutions and technical support.
