Well Drilling Machine For Sale Sold To Argentina

In the field of water resource exploration and extraction, customers have clear requirements for efficient, reliable, and easy-to-operate drilling equipment. A construction company in Argentina was looking for a rig that could adapt to diverse geological conditions, deliver high construction efficiency, and maintain low operating costs. Based on the customer’s needs, YG recommended the YG–300A well drilling machine for sale, providing a comprehensive solution for their water well projects. Feel free to contact us anytime for more product information and exclusive drilling water machine price! In addition, YG also offers truck mounted water well drilling rigs, small water well drilling machines, and full hydraulic core drilling rigs for different applications. 【WhatsApp/WeChat/Phone】+86 13837122632

Get a Free Quote

Well Drilling Machine for Sale Parameters

Model	YG-180	YG–200	YG–300	YG–300A	YG–400	YG–600
Drilling hole diameter	140-254mm	140-305mm	140-325mm	140-325mm	140-350mm	140-350mm
Drilling depth	180m	200m	300m	300m	400m	600m
One-time advance length	3.4m	3.4m	6.6m	3.4m	6.6m	6.6m
Walking speed	2.5km/h	2.5km/h	2.5km/h	2.5km/h	2.5km/h	2.5km/h
Climbing angles (Max.)	30	30	30	30	30	30
Equipped capacitor	55kw	65-70kw	84kw	75.8kw	92kw	115kw
Using air pressure	1.7-2.5mpa	1.7-3.0mpa	1.7-3.3mpa	1.7-3.0mpa	1.7-3.5mpa	1.7-3.5mpa
Air consumption	17-31m³/min	17-30m³/min	17-35m³/min	17-35m³/min	17-35m³/min	17-35m³/min
Drill pipe length	1.5m, 2.0m, 3.0m	1.5m, 2.0m, 3.0m	1.5m, 2.0m, 3.0m,6.0m	1.5m, 2.0m, 3.0m	1.5m, 2.0m, 3.0m,6.0m	1.5m, 2.0m, 3.0m,6.0m
Drill pipe diameter	76mm, 89mm	76mm, 89mm	89mm, 102mm	76mm, 89mm, 102mm	89mm,102mm,108mm	102mm,108mm,114mm
Rig lifting force	15t	12t	20t	16t	22t	28t
Swing speed	45-65rpm	45-70rpm	45–115rpm	40–70rpm	45-115rpm	45–115rpm
Swing torque	3200-4600(N.m)	3500-4800(N.m)	6200-8500(N.m)	5700-7500(N.m)	6500-9000(N.m)	8500-11000(N.m)
Dimension	3800*1500*2200mm	4000*1750*2450mm	5900*2000*2850mm	4100*1950*2600mm	5900*2100*2850mm	6000*2200*2850mm
Weight	4500kg	5800kg	9000kg	7000kg	10000kg	12000kg

Get a Free Quote

Customer Needs Analysis and YG Recommended Solution

• Efficient Construction: The client required a rig with fast drilling and slag removal ability to meet tight project deadlines. Our professional team recommended the YG–300A well drilling machine for sale, equipped with a full hydraulic automation system and high-performance impact slag removal system, capable of breaking rocks quickly and cleaning debris efficiently.
• Multi-Terrain Adaptability: The project area included hills, soft soil, and hard rock. YG suggested choosing a crawler-type chassis design with hydraulic jacks for leveling, ensuring stable operation in complex terrains.
• Low Maintenance Cost: The client expected reduced maintenance over long-term usage. The YG–300A adopts a modular hydraulic system and durable components, making maintenance convenient and reducing overall cost.
• Safety and Precision: The project required high drilling accuracy and operational safety. The YG–300A integrates intelligent control, a pre-filter system, and a compensating slide plate to protect the drill rod, ensuring safe construction and drilling quality.

YG–300a Well Drilling Machine for Sale Advantages

• Full Hydraulic Automation: From mast lifting to drill rod unloading and movement, all steps are completed hydraulically, reducing labor intensity and improving accuracy.
• High-Performance Impact and Slag Removal System: Breaks rocks quickly, clears debris efficiently, extends component life, and ensures continuous operation reliability.
• Flexible Mobility and Stable Positioning: The crawler chassis combined with hydraulic jacks allows stable drilling even in tough terrains, optimizing water drilling equipment for sale adaptability.
• Intelligent Control and Protection: Adjustable torque rotary system, pre-filter reducing 90% of dust entry, and compensating slide plate protecting drill rods, greatly enhancing durability and safety.

Get a Free Quote

YG Services

• Customized Solutions: Based on project environments and requirements, we recommend the most suitable drilling well equipment models and configurations.
• Operation Training: Professional training is provided to help customers quickly master equipment operation.
• After-Sales Support: Maintenance services and spare parts supply, including drill pipes and impactors, are available to ensure long-term reliable operation.

Customer Feedback

The Argentinian customer reported after using the YG–300A well digging equipment for sale:

• Drilling speed is fast, significantly shortening construction cycles.
• Operation is simple, with hydraulic automation reducing manual labor.
• The crawler chassis performed well in hilly and muddy sites, with drilling accuracy meeting expectations.
• After-sales service response was fast, with sufficient spare parts ensuring project continuity.

From this YG–300A export case to Argentina, you can see YG’s strong ability to meet customer needs, provide high-quality well digging equipment for sale, offer competitive drilling water machine price, and deliver comprehensive service. Choosing YG means choosing an efficient, stable, and reliable water well drilling solution. Feel free to contact us anytime! 【WhatsApp/WeChat/Phone】+86 13837122632
