Automatic pipe bender reconstructs pipe processing with “hydraulic drive” + “numerical control brain”! No more worrying about insufficient bending power or inaccurate angles. The hydraulic system outputs stable thrust, easily bending pipes from Φ10 to Φ76mm. The numerical control platform locks angles precisely, with 9 preset groups covering engineering needs. From building pipe networks to industrial pipe fittings, it makes “fast, accurate and stable pipe bending” a norm! Want to know how it doubles processing efficiency? Read on, or contact us directly for quotes and equipment manuals!【WhatsApp/WeChat/Phone】+86 13837122632
Automatic Tube Bending Machine Product Parameters
We offer various models of automatic tube bending machines, such as YG-38, YG-50, and YG-76, covering the processing needs of different steel pipe diameters. Specific parameters are as follows:
| Model | Applicable Steel Pipe Diameter | Motor Power | Spindle Speed | Power Supply | Number of Bending Angles | Applicable Wall Thickness | Overall Dimension | Weight |
| YG-38 | Φ10 – 38mm | 3kw | 25 rpm | 380V50Hz | 9 | ≤3mm | 1100×750×1050mm | 340KG |
| YG-50 | Φ16 – 50mm | 4kw | 25 rpm | 380V50Hz | 9 | ≤3mm | 1450×800×1050mm | 460KG |
| YG-76 | Φ25 – 76mm | 5.5kw | 25 rpm | 380V50Hz | 9 | ≤3mm | 1750×850×1150mm | 750KG |
Automatic Pipe Bender Working Principle
The working process of auto pipe bender is clear and efficient: The motor starts the oil pump, drives the bending cylinder to operate, and pushes the main output shaft through the rack, making the bending device rotate to the position set by the numerical control program. At this time, the motor reverses automatically. When the bending device returns to the stop position, the numerical control program cuts off the circuit, the motor stops, and one bending operation is completed. The whole process is automatically controlled to ensure each bending is accurate.
Auto Pipe Bender Composition Structure
- Bending working device: Includes automatic pipe clamping device and pipe bending fixture, which can firmly clamp pipes to prevent slipping and deviation during bending.
- Bending power device: Composed of motor, hydraulic oil pump, oil cylinder, solenoid valve, magnetic strip, etc., providing stable power output for bending actions.
- Intelligent control device: Equipped with a programmable numerical control system, which can preset bending parameters to realize automatic operation and reduce manual intervention.
Automatic Tube Bender Product Advantages
- Efficient and labor-saving: The automatic operation mode significantly reduces manual participation. A single device can handle the workload that originally required multiple skilled workers, greatly shortening the processing cycle. It can continuously work for a long time without fatigue, ensuring that the production progress is not delayed due to manual factors.
- Accurate and stable: The numerical control system precisely controls the bending angle, with an error within a very small range. This ensures that each product in batch processing has consistent dimensions and angles, avoiding rework caused by errors and reducing material waste.
- Strong adaptability: It is compatible with various pipe materials such as carbon steel, stainless steel, and copper pipes. Combined with different models, it can meet the processing needs of pipes with different diameters and wall thicknesses, adapting to various engineering scenarios.
- Easy to operate: The visual operation interface displays all parameters clearly. Operators can set parameters such as bending angle and speed intuitively. Even beginners can master the operation skills after simple training, reducing the cost of personnel training.
Automatic Pipe Bender – Boosting Efficient Pipe Processing
Automatic pipe bender has become a reliable choice in the pipe processing industry due to its efficiency, accuracy and stability. It is perfectly suitable for both building pipe laying and industrial equipment manufacturing. We provide comprehensive after-sales service to ensure long-term stable operation of the equipment. Choose YG Machinery to make pipe processing more efficient and worry-free. Welcome to contact us at any time! In addition, YG also sells high-quality equipment such as bending machines, rebar straightening and cutting machines, and thread rolling machines!【WhatsApp/WeChat/Phone】+86 13837122632
