Narrow aisles make it difficult for forklifts and traditional stackers to operate flexibly, high-level racks increase the difficulty of material handling, and frequent in-and-out warehouse operations consume a lot of labor costs. In addition, prolonged operation may bring safety hazards and risk of work-related injuries. To address these challenges, fully electric stacker with its full electric drive, high efficiency, stability, and intelligent control has become an ideal choice to optimize warehouse processes and improve operational efficiency. YG Machinery also offers semi-electric stackers, lifting platforms, forklifts, and articulated boom lifts, all hot-selling—contact us for exclusive discounts!【WhatsApp/WeChat/Phone】+86 13837122632
Fully Electric Stacker Specifications
| Parameter Category | Specification | Parameter Category | Specification |
| Model | YG-15 (Stand-Up) | Lowered Height | 90mm |
| Rated Load | 1500kg | Overall Length | 2140mm |
| Load Center | 500mm | Fork Size | 60×170×1100mm |
| Front Overhang | 960mm | Chassis Width | 850mm |
| Wheel Track | 1555mm | Fork Outer Width | 690mm |
| Weight (with Battery) | 700 – 1100kg | Ground Clearance at Wheelbase | 40mm |
| Wheels | Polyurethane | Turning Radius | 1600mm |
| Front Wheel Size | 250×80mm | Drive Type | Electric (Battery) |
| Rear Wheel Size | 80×70mm | Travel Speed (Full/No Load) | 4/5.6km/h |
| Front Wheel Track | 886mm | Lifting Speed (Full/No Load) | 0.08/0.1m/s |
| Rear Wheel Track | 525mm | Lowering Speed (Full/No Load) | 0.12/0.09m/s |
| Lifting Height | 1600 – 3500mm | Gradeability | 6/10% |
| Lifting Motor Power | 2.2kW | Service Brake | Electromagnetic |
| Battery 24V | 120/130Ah | Drive Motor Power | 1.5kW |

Fully Electric Stacker Features
- Automated Operation, Reducing Labor Costs
Full electric stacker achieves fully automated operation through a complete electric drive system. Compared to semi-electric equipment, it not only improves operational efficiency but also significantly reduces labor costs. For example, its multifunction smart handle integrates all control functions, allowing operators to easily perform lifting, moving, and speed adjustment with a single device, greatly simplifying workflow. This design makes it especially suitable for high-frequency, high-intensity warehouse environments. - Technical Features and Innovation
Full electric stacker uses a full AC polyurethane drive assembly, which is more stable than traditional DC systems and requires no brush replacement, reducing maintenance needs. The high-power motor ensures quiet, durable operation while the electronic power steering provides light and flexible handling. For safety, the equipment is equipped with curve auto-slowdown and fork high-level travel auto-slowdown functions, further ensuring operational security. These features make it an ideal choice for companies seeking reliability and intelligent operation.

Fully Powered Stackers Application Scenarios
- High-Level Warehouse Operations
Fully powered stackers can easily complete stacking and retrieval tasks on high-level racks. With electric drive and precise electronic control systems, operators can quickly adjust fork height and travel speed for accurate material handling. Its high stability reduces collisions and operational errors, improving overall efficiency. - Flexible Operations in Narrow Aisles
Modern warehouses often have narrow aisles and high space utilization. Fully electric stackers feature compact design, short wheelbase, and electronic power steering, allowing flexible movement in tight spaces. Even in narrow passages, the equipment maintains smooth travel, reducing operational difficulty and ensuring continuous warehouse operations. - High-Frequency Handling in Logistics Centers
In logistics centers with frequent in-and-out operations, fully powered stackers can perform continuous, high-speed handling. The electric drive system for travel and lifting ensures rapid response, significantly increasing warehouse throughput and operational efficiency while reducing human error. - Precision Material Handling
They are suitable for handling high-precision goods, such as fragile items, precision instruments, or high-value products. Electronic control allows operators to precisely adjust lifting height and travel speed, ensuring cargo safety, smooth handling, and minimizing damage or material waste. - Comprehensive Warehouse Solutions
Fully electric stackers are suitable not only for large warehouses but also improve efficiency in medium and small logistics environments. They are easy to operate, safe, and reliable, capable of handling a variety of goods, optimizing warehouse layout, and achieving efficient, energy-saving modern warehouse management.
As a professional manufacturer, YG Machinery strictly controls every process in the production of fully electric stacker, ensuring stable and reliable operation even under high load and long-duration use. Choosing YG Machinery means a confident purchase, gaining a highly efficient, safe, and durable warehouse handling solution. Contact us anytime to get an exclusive electric stacker price!【WhatsApp/WeChat/Phone】+86 13837122632
